TMC3-150-1 - Eaton Conduit & Fittings Cable Gland

TMC3-150-1

TMC3-150-1 is an Eaton Crouse-Hinds series cable gland designed for secure terminations in industrial electrical systems. This aluminum cable gland provides a mechanical watertight connection suitable for metal-clad cable, TECK corrugated cable, and non-armored tray cables in junction boxes, control centers, panelboards, and motor control enclosures. The gland is rated for Class I, Division 2 locations (provided there are no arcing and sparking risks per NEC 501.10B) and offers IP66 and NEMA 4X protection. It features a two-piece construction with dual certification for both armored and non-armored cables, standard gasket and locknut for improved ingress protection, and corrosion-resistant copper-free aluminum construction. The extreme temperature range is -60°C to +109°C, making it suitable for demanding industrial environments. Key Specifications

• Part Number: TMC3-150-1
• Manufacturer: Eaton
• Material: Copper-free aluminum
• Trade Size: 1-1/2 in NPT
• Armor Range: 1.280 in - 1.610 in (min./max.)
• Cable Range: 1.380 in - 1.780 in (min./max.)
• Ingress Protection: IP66, NEMA 4X
• Temperature Range: -60°C to +109°C
• Certifications: Class I Division 2, ATEX/IECEx
• Cable Type: Armoured and non-armoured

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: TMC3-150-1
• Manufacturer : Eaton
• Brand : Eaton
• Category : Conduit & Fittings
• Item Subcategory : Cable glands and cord grips
• Section : TMC3 Armored Gland
• Nema Rating : NEMA 4X
• Operating Temperature Maximum Celsius : -60°C to +109°C
• Installation Type : Two-piece construction
• Enclosure Grade : IP66
• Material : Copper-free aluminum
• NEC hazardous rating : Class II, Division 1 Class III
• Ingress protection (IP) ratings : IP66
• Trade size : 1-1/2 in NPT
• Certifications and compliances : Class I Division 2, ATEX/IECEx
• Special features : Dual certified for armored and non-armored cables, watertight connection

Product Data

• UPC : 662277129978
• Dimensions : 6.03 in x 2.75 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 1.28 lb
