Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THQMV150WL
THQMV150WL is a General Electric 2 pole thermal magnetic circuit breaker rated for 150 amps and 120/240 volts AC with top feed mounting.This molded case circuit breaker features a 22kA interrupting rating at 240VAC, long time and instantaneous trip functions, and a plug-in connection type. It is designed for use with PowerMark Gold load centers and has a THQL frame type with lug terminal connections.
- Manufacturer: General Electric
- Series: THQ
- Amperage: 150 A
- Voltage: 120/240 VAC
- Poles: 2
- Mounting Type: Top Feed
- Interrupting Rating: 22kAIC at 240VAC
- Frame Type: THQL
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
- Connection Type: Plug-In
- Terminal Connection: Lug
- Compatible with PowerMark Gold Load Centers
Specifications
- Part Number: THQMV150WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : PowerMark Gold
- Type : THQMV
- Voltage : 120
- Amperage : 150
- Phase : 1
- Poles : 2
- AIC rating : 22kA@240V
- Connection : Plug-In
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 783164163209
- GTIN : 00783164163209
- Weight : 1 lb
