Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THQL21125
THQL21125 is a General Electric 2 Pole thermal magnetic circuit breaker rated for 125 Amps and 240VAC voltage. It is designed for residential and commercial electrical protection.
This Q-Line series molded case circuit breaker features a plug-in connection type, long-time and instantaneous trip functions (LI trip unit), and a 10kA interrupting rating at 120V. It is UL listed and suitable for use in load centers and lighting panels with a compact 1-inch wide per pole frame.
- Key Specifications
- Amperage: 125 A
- Voltage: 120/240 VAC
- Poles: 2
- Series/Frame: Q-Line (THQL)
- Trip Unit: Thermal Magnetic with Long-Time and Instantaneous (LI) trip
- Interrupt Rating: 10 kAIC at 120V
- Mounting Type: Plug-In
- UL Listed
- Terminal Connection: Load Side Lug
- Compact 1-inch wide per pole design
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: THQL21125
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : THQL
- Voltage : 240
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 10kA@120V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 783164081909
- GTIN : 40783164081907
- Dimensions : 3" X 4" 2"
- Weight : 0.72 lb
- Certification : Ul Listed
- Wire Size : 2 To 2/0 Awg (Copper/Aluminum)
