Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THQC1125WL
THQC1125WL is a General Electric 25 Amp, 1 Pole circuit breaker designed for 120/240V AC applications with a 10kA interrupt rating.This THQC series molded case circuit breaker features thermal magnetic trip functions with long time and instantaneous trip capabilities. It supports feed-thru mounting with line and load side lug terminals, suitable for single-phase electrical systems. The breaker is HACR rated and designed for reliable protection in residential and commercial installations.
- Amperage: 25 Amp
- Voltage Rating: 120/240V AC
- Number of Poles: 1
- Interrupt Rating: 10kA at 120/240V AC
- Frame Type: THQC
- Trip Unit: Thermal Magnetic
- Mounting Type: Feed-Thru
- Phase: Single Phase
- Terminal Connection: Lug-Lug (Line & Load)
- HACR Rated
- Dimensions: Approx. 1.00"W x 3.94"L x 2.63"D
Specifications
- Part Number: THQC1125WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : THQC
- Voltage : 240
- Amperage : 25
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164059953
- GTIN : 00783164059953
- Weight : 0.35
