Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THJK426F000
THJK426F000 is a General Electric 2 pole molded case circuit breaker rated for 400 amps and 600 volts AC with a TJK frame.This circuit breaker features a thermal magnetic trip unit providing long time and instantaneous trip functions. It has a high interrupting capacity of 35kA at 480V and is designed for bolt-on mounting. The breaker is single phase and part of the J600 series, suitable for commercial and industrial power distribution applications.
- Amperage: 400A
- Voltage: 600V AC
- Number of Poles: 2
- Frame Type: TJK
- Interrupt Rating: 35kA at 480V
- Trip Unit: Thermal Magnetic (Long Time and Instantaneous)
- Mounting Type: Bolt-On
- Phase: Single Phase
- Series: J600
- High Interrupting Capacity
- UL Listed
- Suitable for commercial and industrial use
Specifications
- Part Number: THJK426F000
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 400
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip Functions
- Protection : Thermal Magnetic
Product Data
- GTIN : 40783164010587
- Weight : 15
- Certification : UL, CSA, NOM, IEC
