THED136045WL - General Electric 45 Amp 600V 3 Pole Thermal Magnetic Circuit Breaker TED Frame

Save $717.53
SKU: THED136045WL-New
Condition: New
Price:
$782.47 $1,500.00
Stock:
Low inventory, please call for stock check

💡 ABB / GE Branding Notice

On June 30, 2018, ABB completed the acquisition of GE Industrial Solutions.

As a result of this transition, certain products may be labeled as either ABB or GE depending on the manufacturing date and production batch. In many cases, the product itself remains identical in form, fit, function, and specifications, with only the branding or label differing.

Customers may receive:

  • ABB-branded products
  • GE-branded products
  • Packaging reflecting either brand

Unless otherwise stated, these are considered the same product and are fully interchangeable under the applicable manufacturer specifications.

If you have questions regarding labeling, compatibility, or product identification, please contact our support team prior to ordering.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

THED136045WL - General Electric Feed-Thru 600V 45A 3 pole circuit breaker 25kA@480V - Essential Electric Supply
THED136045WL - General Electric 45 Amp 600V 3 Pole Thermal Magnetic Circuit Breaker TED Frame - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
THED136045WL - General Electric Feed-Thru 600V 45A 3 pole circuit breaker 25kA@480V - Essential Electric Supply
THED136045WL - General Electric 45 Amp 600V 3 Pole Thermal Magnetic Circuit Breaker TED Frame - Essential Electric Supply

Description

THED136045WL


THED136045WL is a General Electric 3 Pole thermal magnetic molded case circuit breaker rated for 45 Amps and 600 Volts AC.

This circuit breaker features a TED frame type with thermal magnetic trip unit providing long time and instantaneous trip functions. It supports 3-phase feed-thru applications and has a high interrupting capacity of 25kA at 480V. The breaker includes line and load side lug terminals for easy installation and is rated for operation at 40 degrees Celsius.

  • Manufacturer: General Electric
  • Part Number: THED136045WL
  • Amperage: 45 Amps
  • Voltage: 600 Volts AC
  • Poles: 3
  • Frame Type: TED
  • Trip Unit: Thermal Magnetic
  • Interrupt Rating: 25kA at 480V
  • Mounting Type: Molded Case
  • Feed-Thru Capability
  • Line and Load Side Lug Terminals
  • Operating Temperature: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

  • Part Number: THED136045WL
  • Manufacturer : General Electric
  • Brand : General Electric
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : E150 Line
  • Type : THED
  • Voltage : 600
  • Amperage : 45
  • Phase : 3
  • Poles : 3
  • AIC rating : 25kA@480V
  • Connection : Feed-Thru
  • Functions : LI - Long-Time and Instantaneous Trip
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 078316406281
  • GTIN : 00783164062816
  • Weight : 3

Accesories

Part Manufacture Sub Category
TEDAS2AB1
TECBAL
TEDMOMA1
