Product Info
- Manufacturer: General Electric
- Sub-Category: Molded Case
Description
TED134030WL
TED134030WL is a General Electric 3-pole, 30 amp thermal magnetic circuit breaker designed for 480VAC applications.TED134030WL features a non-interchangeable trip unit with a fixed long time and instantaneous trip, suitable for electrical distribution and control. It belongs to the E150 series frame and offers an interrupting rating of 18kA at 480VAC and 10kA at 500VDC, with line and load side lug terminals for easy installation. Certified to UL and CSA standards, it supports reverse feed and includes HACR markings.
- Amperage: 30 A
- Voltage: 480 VAC (also rated up to 600 VAC)
- Poles: 3
- Frame Type: E150
- Interrupting Rating: 18 kA at 480 VAC, 10 kA at 500 VDC
- Trip Unit: Thermal Magnetic, Non-Interchangeable
- Mounting Type: Lug terminals (line and load side)
- Trip Function: Fixed Long Time and Instantaneous
- Suitable for Reverse Feed: Yes
- Certifications: UL File #E11592, CSA File #LR57114
- Special Markings: HACR
Specifications
- Part Number: TED134030WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : E150 Line
- Type : TED
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164063042
- GTIN : 40783164063040
- Weight : 3
- Certification : UL
