SP500MQMJ - Hammond Power Solutions 500 VA 1-Phase Control Transformer 240/480 VAC Primary 120/240 VAC Secondary Panel Mount

SP500MQMJ

SP500MQMJ is a Hammond Power Solutions 500 VA single-phase control transformer designed for industrial applications.SP500MQMJ features a 240/480 VAC primary voltage and 120/240 VAC secondary voltage with a 50/60 Hz frequency rating. It is an open core dry type transformer suitable for panel mounting, providing reliable voltage transformation for control circuits.

Key Specifications
• Power Rating: 500 VA
• Phase: Single Phase
• Primary Voltage: 240/480 VAC
• Secondary Voltage: 120/240 VAC
• Frequency: 50/60 Hz
• Mounting Type: Panel Mount
• Transformer Type: Control Transformer
• Construction: Open Core Dry Type
• Dimensions: 4.49 in L x 4.69 in W x 3.78 in H
• Series: HPS Spartan
• Certifications: UL, CSA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SP500MQMJ
• Manufacturer : Hammond Power Solutions
• Brand : Hammond Power Solutions
• Category : Transformer
• Phase : 1
• Enclosure Grade : N / A
• Frequency : 50/60Hz
• Primary Voltage : 240x480
• Primary Connection : Parallel x Series (Vx2V)
• Secondary Voltage : 120x240
• Secondary Connection : Parallel x Series (Vx2V)
• Material : Copper
• Temperature Rise : 80°C
• Insulation Class : 130°C
• EKVA : 0.740621
• Seismic Compliance : OSHPD, IBC 2018 (Sds=2.0, z/h=1, lp=1.5)
• Enclosure Type : Core & Coil
• Nameplate : Standard
• Vector Configuration : 180°
• Seismic Standard Value : IBC 2018
• OSHPD : Yes
• Seismic IP : lp=1.5
• Seismic ZH : z/h=1
• Seismic SDS Value : Sds=2.0
• Primary Termination (Std) : Terminal Block

Product Data

• UPC : 803423098803
• Weight : 11
• Certification : CSA, UL, CE
