SL100 - Square D 100 Amp 3 Pole 600V AC SL Frame Circuit Breaker Sub Feed Lug

SL100

SL100 is a Square D 100 Amp 3 Pole circuit breaker sub feed lug kit designed for SL frame panelboards.This device is rated for 100 amps and 600 volts AC, compatible with SL type frames, and supports 3 poles. It features a plug-on mounting type suitable for I-line panelboards and has a 10k AIC interrupt rating at 240 VAC. The SL100 is intended as a sub-feed lug accessory without over-current protection, ideal for residential, commercial, and industrial electrical setups.

• Amperage: 100 Amp
• Voltage: 600 VAC
• Poles: 3
• Frame Type: SL
• Mounting Type: I-line Plug-on
• Interrupt Rating: 10k AIC @ 240 VAC
• Application: Sub Feed Lug Kit
• Compatible with Square D SL Series
• Dimensions approx: 4.50"H x 3.00"L x 2.50"D
• Weight: Approx. 3.87 lbs
• Certifications: OEM Square D / Schneider Electric

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SL100
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Lug Terminal Kit
• Family : I-Line
• Type : SL
• MCM Size : 106
• Barrels : 1
• Metal Type : Aluminum
• Compatible Frames : LA,LH,LC,LI,LX,LE,MA,MH

Product Data

• UPC : 018997131003
• GTIN : 00785901206484
• Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
• Weight : 1 lb
• Panel Type : Panelboard HCP 85.98 in (2184 mm) 42.01 in (1067 mm)
  Panelboard HCP-SU 85.98 in (2184 mm) 25.98 in (660 mm)
• Certification : UL - CSA
• Wire Size : AWG 14...AWG 1/0 copper
  AWG 12...AWG 1/0 aluminium
