Hammond Power Solutions SK3A0750PB3K - 3-Phase Transformer 750kVA 600D-208Y/120V

SK3A0750PB3K

Hammond Power Solutions SK3A0750PB3K is a three-phase general duty transformer designed for industrial power distribution applications. This unit features a 600V delta primary connection with multiple voltage taps and delivers 208Y/120V secondary power through a wye-N configuration with 750 kVA capacity. The transformer is housed in a Type 3R/IP24 rated enclosure measuring 64"H x 49"W x 39"D with ANSI 61 grey finish, providing robust outdoor protection while maintaining a 67 dBA sound level. It complies with DOE 2016, NRCAN 2019, and NMX 2021 efficiency regulations and meets IBC 2018 seismic requirements (Sds=2.0, z/h=0, lp=1.5). This transformer is suitable for commercial buildings, industrial facilities, and utility applications requiring reliable three-phase power conversion with 150°C temperature rise and 220°C insulation class ratings. Key Features & Specifications

• Type: Three-Phase General Duty Transformer
• Primary Voltage: 600V Delta
• Secondary Voltage: 208Y/120V Wye-N
• Capacity: 750 kVA
• Frequency: 60 Hz
• Impedance: 4% - 7.5%
• Temperature Rise: 150°C
• Insulation Class: 220°C
• Enclosure: Type 3R/IP24
• Dimensions: 64"H x 49"W x 39"D
• Sound Level: 67 dBA
• Efficiency Compliance: DOE 2016, NRCAN 2019, NMX 2021
• Seismic Standard: IBC 2018

Specifications

• Part Number: SK3A0750PB3K
• Manufacturer : Hammond Power Solutions
• Brand : Hammond Power Solutions
• Category : Transformer
• Phase : 3
• Enclosure Grade : Standard
• Duty : General Duty
• Frequency : 60Hz
• Primary Voltage : 600D
• Primary Connection : Delta
• Primary FCAN (NPL) : 2x2.5%
• Primary FCBN (NPL) : 4x2.5%
• Secondary Voltage : 208Y/120
• Secondary Connection : Wye-N
• Temperature Rise : 150°C
• Insulation Class : 220°C
• EKVA : 1000.62
• Efficiency Regulation : DOE 2016 (US), NRCAN 2019 (Canada), NMX 2021 (Mexico)
• Seismic Compliance : IBC 2018 (Sds=2.0, z/h=0, lp=1.5)
• Sound Level : 67 dBA (NEMA ST-20)
• Impedance (Std) : 4% - 7.5%
• Secondary Termination (NPL) : Mounting Pads
• Enclosure Type : Type 3R / IP24
• Enclosure Finish : ANSI 61 Grey, UL50
• Enclosure PN (NPL) : DH6-N3R
• Enclosure Dimensions : 64in/1626mm(H), 49in/1245mm(W), 39in/991mm(D)
• Electrostatic Shield : Single
• Nameplate : Standard
• Standard kVA : 750
• Vector Configuration : Dyn1 (-30°)
• Seismic Standard Value : IBC 2018
• OSHPD : No
• Seismic IP : lp=1.5
• Seismic ZH : z/h=0
• Seismic SDS Value : Sds=2.0
• Enclosure IR Window : No

Product Data

• UPC : 803423130480
• Weight : 4550
• Certification : CSA, UL
