SHC1041CR - Hubbell 1 in NPT Straight Male Cord Connector, Nylon, .63-.75 in Cord Diameter, Gray/Yellow

SHC1041CR

SHC1041CR is a straight male cord connector made from gray nylon, designed for use with 1 in NPT hubs and .63-.75 in diameter cords. This connector provides a secure and durable connection for industrial and commercial wiring applications. The SHC1041CR features a standard F4 form size and is constructed from UL 94-V2 rated nylon for reliable performance in demanding environments. It is suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, and Class III Div. 1 & 2. The connector is UL Listed, CSA Certified, and meets United States Coast Guard approval requirements. It is RoHS compliant and rated for temperatures from -30°F to +225°F (-34°C to +107°C).

• Part Number: SHC1041CR
• Manufacturer: Hubbell
• Material: Gray Nylon
• Body Style: Straight Male
• Form Size: F4
• NPT Hub Size: 1 in
• Cord Diameter Range: .63-.75 in (15.9-19.0 mm)
• Color: Gray/Yellow
• Operating Temperature: -30°F to +225°F (-34°C to +107°C)
• Mounting Hardware: Locknut or Tapped Opening
• Certifications: UL Listed, CSA Certified, United States Coast Guard Approval, RoHS Compliant
• Standards: NEMA Type 4, 4X, 12, 13
• Hazardous Locations: Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2
• Dimensions: 1.88 in x 1.88 in x 2.45 in
• Weight: 0.3 lb
• UPC: 783585208138

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SHC1041CR
• Manufacturer : Hubbell
• Brand : Hubbell
• Category : Conduit & Fittings
• Family : SHC

Product Data

• UPC : 783585208138
• GTIN : 00783585208138
• Country of Origin : United States
• Dimensions : 1.88 in L x 1.88 in W x 2.45 in H
• Weight : 3.5 lb
• Certification : CSA LR27378, UL E54218(M)
