SCLR400 - Edison Fuses 400A 600V Class RK1 Fast-Acting Fuse

SCLR400

SCLR400 is a 400A, 600V Class RK1 fast-acting fuse designed for reliable circuit protection in industrial and commercial applications. This Edison Fuses product features a current-limiting design and is built to deliver consistent performance under demanding conditions. The SCLR400 fuse is constructed with a glass melamine tube and is rated for temperatures from -40° to 85°C. It is non-indicating and provides a high interrupting rating for safety and reliability. Suitable for use in a wide range of electrical systems, this fuse is UL and CSA C22.2 approved.

• Amperage Rating: 400A
• Voltage Rating: 600V AC
• Fuse Type: Class RK1
• Response Time: Fast-Acting
• Interrupting Rating: 200,000A RMS Symmetrical
• Mounting Type: Edison SCLR Series
• Operating Temperature: -40° to 85°C
• Certifications: UL, CSA C22.2
• Frame/Enclosure: Glass Melamine Tube
• Indicating Type: Non-Indicating
• Series: SCLR
• Application: Industrial, Commercial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SCLR400
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : SCLR Series
• Type : SCLR
• Voltage : 600
• Amperage : 400
• AIC rating : 200kA@600V
• Connection : Ferrule
• Diameter : 2.59
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 782634417255
• GTIN : 00782634000000
• Dimensions : 11.63 in x 2.36 in x 2.36 in (Length/Depth x Height x Width)
• Weight : 2.358
