Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
SC-7
SC-7 is a 7 Amp, 600 Volt AC, Class G fast acting fuse from Eaton designed for reliable circuit protection.SC-7 features current limiting and size-rejecting design, with a 100,000 A interrupt rating at 600 VAC and 10,000 A at 170 VDC. It is UL Listed and CSA Certified, meeting stringent safety standards for industrial and commercial applications.
- Key Specifications
- Amperage: 7 Amps
- Voltage Rating: 600 VAC, 170 VDC
- Fuse Class: G
- Fuse Type: Fast Acting, Current Limiting
- Interrupting Rating: 100,000 AIC at 600 VAC, 10,000 A at 170 VDC
- Physical Size: 0.41" x 1.31"
- Mounting Type: Cartridge Fuse
- Certifications: UL Listed (Std. 248-5), CSA Certified
- Series: Bussmann SC
Specifications
- Part Number: SC-7
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : SC Series
- Type : SC
- Voltage : 600
- Amperage : 7
- AIC rating : 100kA@600V
- Diameter : 0.41
- Class Rating : G
- Barrels : 1
Product Data
- UPC : 051712189972
- GTIN : 00051712189972
- Dimensions : 1.31 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
- Weight : 0.1
