SC-5 - Eaton Bussmann 5A 600V Class G Fast-Acting Current Limiting Fuse Rejection Style

SC-5

SC-5 is a 5 amp, 600 volt AC, Class G fast-acting, current limiting fuse from Eaton Bussmann series designed for reliable circuit protection.This SC-5 fuse features a rejection style design with ferrule end connections, providing a 100 kA interrupt rating at 600 VAC and 10 kA at 170 VDC. It is non-indicating and UL Listed to standard 248-5, CSA certified, CE marked, and RoHS compliant.

• Amperage: 5 A
• Voltage Rating: 600 VAC, 170 VDC
• Interrupt Rating: 100 kA at 600 VAC, 10 kA at 170 VDC
• Fuse Class: Class G
• Fuse Type: Fast-Acting, Current Limiting
• Connection: Ferrule end x ferrule end
• Style: Rejection style
• Non-indicating
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Physical Size: 0.41 in x 1.31 in

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SC-5
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : SC Series
• Type : SC
• Voltage : 600
• Amperage : 5
• AIC rating : 100kA@600V
• Diameter : 0.41
• Class Rating : G
• Barrels : 1

Product Data

• UPC : 051712250054
• GTIN : 00051712250054
• Country of Origin : Mexico
• Dimensions : 1.31 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.1
• Certification : CE, CSA Guide 1422-01, UL 248-5 Guide JDDZ
