SC-4 - Eaton Bussmann Cooper Bussmann 4A 600VAC Fast-Acting Current Limiting Class G Fuse, Size-Rejecting, 100kA IR

SC-4

SC-4 is a fast-acting, current-limiting, size-rejecting Class G fuse designed for reliable circuit protection in demanding applications.

This Eaton Bussmann (Cooper Bussmann) SC-4 fuse offers fast-acting protection for circuits rated 1/2 to 6A, with a robust interrupting rating and rejection-style design to prevent overfusing. It is UL Listed, CSA Certified, CE marked, and RoHS compliant, ensuring compliance with international safety standards.

Key Specifications
• Part Number: SC-4
• Manufacturer: Eaton Bussmann / Cooper Bussmann
• Amperage: 4A
• Voltage: 600VAC (1/2-20A), 480VAC (25-60A)
• Poles: 1
• Mounting Type: Fuse Holder (rejection style)
• Interrupt Rating: 100kA RMS Symmetrical at 600VAC, 10kA at VDC
• Series/Frame: SC Class G
• Trip Unit: Fast-acting (1/2-6A), Time-delay (7-60A)
• Certifications: UL Listed (248-5, Class G), CSA Certified (C22.2 No. 248.5), CE, RoHS
• Application: Branch circuit protection
• Rejection Feature: Prevents installation of incorrect fuse sizes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SC-4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : SC Series
• Type : SC
• Voltage : 600
• Amperage : 4
• AIC rating : 100kA@600V
• Diameter : 0.41
• Class Rating : G
• Barrels : 1

Product Data

• UPC : 051712250139
• GTIN : 00087115731203
• Country of Origin : Mexico
• Dimensions : x 1-5/16 in x
• Weight : 2.6
• Certification : CE, CSA Guide 1422-01, UL 248-5 Guide JDDZ
