SC-3 - Eaton Bussmann 3A 600V Class G Fast Acting Fuse, Rejection Style, 1-Pole, 100kA Interrupt Rating

SC-3

SC-3 is an Eaton Bussmann series Class G fast-acting fuse designed for reliable circuit protection.This 3 amp, 600 volt AC fuse features a rejection style ferrule end connection and provides current-limiting protection with a high interrupt rating of 100 kA at 600 VAC and 10 kA at 170 VDC. It is a non-indicating, standard size fuse with a compact 1.31 inch length and 0.41 inch diameter, suitable for use in 1-pole fuse blocks. The SC-3 fuse complies with UL Class G standards and is CSA certified, making it ideal for industrial and commercial electrical applications.

Key Specifications
• Amperage: 3 A
• Voltage Rating: 600 VAC, 170 VDC
• Interrupt Rating: 100 kA at 600 VAC, 10 kA at 170 VDC
• Class: G
• Poles: 1
• Mounting Type: Rejection style, ferrule end x ferrule end
• Fuse Indicator: Non-indicating
• Size: 1.31 in length, 0.41 in diameter
• Connection Type: Ferrule design, Type P
• Certifications: UL Listed, CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: SC-3
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : SC Series
• Type : SC
• Voltage : 600
• Amperage : 3
• AIC rating : 100kA@600V
• Diameter : 0.41
• Class Rating : G
• Barrels : 1



Product Data

• UPC : 051712250030
• GTIN : 00051712250030
• Country of Origin : Mexico
• Dimensions : 1.31 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.163
• Certification : CE, CSA Guide 1422-01, UL 248-5 Guide JDDZ
