Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
SC-12
SC-12 is a Cooper Bussmann Class G fast-acting fuse rated for 12 amps and 600 volts AC, designed for reliable low voltage circuit protection.SC-12 features a size-rejecting design with a 1-barrel melamine tube construction, providing a 100kA interrupting rating at 600 VAC and 10kA at 170 VDC. It is UL Listed, CSA Certified, and RoHS compliant, suitable for branch circuit protection requiring fast-acting characteristics.
- Key Specifications
- Amperage: 12A
- Voltage Rating: 600 VAC / 170 VDC
- Fuse Class: Class G
- Poles: 1
- Mounting Type: Size-rejecting cartridge
- Interrupting Rating: 100kA AC, 10kA DC
- Fuse Type: Fast-acting, current limiting
- Dimensions: Diameter 0.41 inches, Length approx. 2.25 inches
- Certifications: UL Listed (Std. 248-5), CSA Certified, CE, RoHS compliant
- Series: SC Series
Specifications
- Part Number: SC-12
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : SC Series
- Type : SC
- Voltage : 600
- Amperage : 12
- AIC rating : 100kA@600V
- Diameter : 0.41
- Class Rating : G
- Barrels : 1
Product Data
- UPC : 005171218985
- GTIN : 00051712189859
- Weight : 1
