SC-10 - Eaton Bussmann 10A 600V Class G Time Delay Current Limiting Fuse

SC-10

SC-10 is an Eaton Bussmann Class G time-delay current limiting fuse rated for 10 amps and 600 volts AC.

This SC series fuse features a rejection style design with ferrule end connections, providing reliable circuit protection with a 100 kA interrupt rating at 600 VAC and 10 kA at 170 VDC. It has a response time of 12 seconds at 200% overload and meets UL 248-5 and CSA C22.2 No. 248.5 certifications. The fuse is non-indicating and measures 0.41 inches in diameter by 1.31 inches in length.

Key Specifications
• Amperage Rating: 10 A
• Voltage Rating: 600 VAC, 170 VDC
• Interrupting Rating: 100 kA at 600 VAC, 10 kA at 170 VDC
• Fuse Type: Time Delay (Class G)
• Connection: Ferrule end x ferrule end
• Response Time: 12 seconds at 200% overload
• Physical Size: 0.41" diameter x 1.31" length
• Fuse Indicator: Non-indicating
• Series: Bussmann SC
• Certifications: UL Listed, CSA Certified
• Special Features: Rejection style for size protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: SC-10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : SC Series
• Type : SC
• Voltage : 600
• Amperage : 10
• AIC rating : 100kA@600V
• Diameter : 0.41
• Class Rating : G
• Barrels : 1

Product Data

• UPC : 051712250108
• GTIN : 00051712250108
• Country of Origin : Mexico
• Dimensions : 1.31 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.1
• Certification : CE, CSA Guide 1422-01, UL 248-5 Guide JDDZ
