S203P-K10 - ABB 3 Pole 10 Amp 480V K-Trip Curve Miniature Circuit Breaker DIN Rail Mount

S203P-K10

S203P-K10 is a 3 pole, 10 amp miniature circuit breaker from ABB designed for DIN rail mounting and rated for 480 volts AC operation.

This ABB S203P-K10 circuit breaker features a K trip curve suitable for short circuit and overload protection. It has a rated interrupt capacity of 10 kA at 480V AC and complies with IEC and UL standards for residential, commercial, and industrial applications. The breaker uses a combination of thermal and electromechanical tripping mechanisms to ensure reliable current limiting protection. It is part of the System pro M compact S200P series and supports flexible installation with a failsafe bi-directional cylinder-lift terminal and a recommended tightening torque of 2.8 Nm.

Key Specifications
• Poles: 3
• Rated Current: 10 Amps
• Rated Voltage: 480V AC (277/480Y)
• Trip Curve: K
• Interrupt Rating: 10 kA at 480V AC
• Mounting Type: DIN Rail
• Product Series: System pro M compact S200P
• Tripping Mechanism: Thermal and Electromechanical
• Terminal Type: Cylinder-lift, bi-directional
• Tightening Torque: 2.8 Nm
• Standards: IEC/EN 60898-1, IEC/EN 60947-2, UL1077

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: S203P-K10
• Manufacturer : ABB
• Brand : ABB
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : S 200 P Series
• Type : S203P-K
• Voltage : 480
• Amperage : 10
• Phase : 3
• Poles : 3
• AIC rating : 10kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Dimensions : Depth / Length 69 mm X Height 88 mm X Width 52.5 mm
• Weight : 0.95
• Certification : CSA IEC EN UL
