Product Info
- Manufacturer:WEG
- Sub-Category:Overload Relay
Description
RW117-2D3-U097
The RW117-2D3-U097 is a thermal overload relay manufactured by WEG, designed to protect electric motors from overheating due to overloads or phase loss. It is suitable for use with WEG’s CWM112 to CWM150 contactors. Specifications: • Current Range: Adjustable between 75 to 97 amperes • Voltage Rating: Up to 690 V • Trip Class: 10 • Poles: Three-pole bimetallic design • Auxiliary Contacts: 1 Normally Open (NO) and 1 Normally Closed (NC) • Standards Compliance: IEC 60947-4-1, IEC 60529, IEC 60068, VDE 0106, UL-508 Features: • Phase Failure Sensitivity: Detects and responds to phase loss conditions to protect the motor. • Temperature Compensation: Ensures consistent performance across a wide temperature range. • Manual or Automatic Reset: Offers flexibility in operation with selectable reset modes. • Adjustable Multifunction Button: Provides HAND, AUTO, H, or A settings for tailored control. Every part Essential Electric sells is also backed by our industry-leading gold standard 2-year warranty.
Specifications
- Part Number: RW117-2D3-U097
- Manufacturer : WEG
- Brand : WEG
- Category : Motor Control
- Item Subcategory : Overload Relay
- Family : CWM Series
- Type : RW
- Voltage : 690
- Amperage : 75-97
- Poles : 3
- Amperage Maximum : 97
- Amperage Minimum : 75
Product Data
- UPC : 7890355027745
- GTIN : 07890355027745
- Dimensions : 3.94 inches (height) x 2.95 inches (width) 3.89 inches (depth)
- Weight : 1.6 lb
