Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Rating Plug
Description
RP6R16A120
RP6R16A120 is a Cutler Hammer circuit breaker rating plug kit designed for use with Magnum series breakers.This sensor and rating plug kit supports 1200A continuous current at 50/60 Hz frequency, compatible with three-pole universal frame breakers, and is rated for up to 1600A uninterrupted current. It integrates with DIGITRIP trip units including RMS510, RMS610, RMS810, and RMS910, providing reliable trip sensing and rating functionality.
- Manufacturer: Cutler Hammer
- Amperage: 1200A continuous, up to 1600A interrupt rating
- Poles: 3
- Frequency: 50/60 Hz
- Frame Type: Universal
- Compatible Trip Units: DIGITRIP RMS series (510, 610, 810, 910)
- Product Type: Sensor and Rating Plug Kit
- Application: Magnum series circuit breakers
- Mounting: Plug-in
- Interrupt Rating: 1600A
Specifications
- Part Number: RP6R16A120
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Rating Plug
- Family : Series G
- Amperage Maximum : 1600
- Amperage Minimum : 1600
- Compatible Frames : RD,RDC,CRD,CRDC,RGH,RGC,RW,RWC
- Trip Type : DIGITRIP,RMS510,RMS610,RMS810,RMS910
Product Data
- UPC : 078667948608
- GTIN : 00786679486085
- Dimensions : 5.8 in x 1.8 in x 2.8 in (Length/Depth x Height x Width)
- Weight : 0.1
