RJA36120CU33A - Square D 1200A 600VAC 3 Pole Molded Case Circuit Breaker I-Line Frame

RJA36120CU33A

RJA36120CU33A is a Square D 3 pole molded case circuit breaker rated for 1200 amps and 600 volts AC, designed for reliable power distribution protection.This circuit breaker features an I-Line mounting type with a 25kA interrupt rating at 600VAC, suitable for industrial and commercial applications. It includes a Micrologic 5.0 trip unit and meets certifications including UL, CSA, and NOM. The breaker provides HACR rating and is built for continuous 100% current rating with a robust molded case design.

Key Specifications
• Amperage: 1200A
• Voltage Rating: 600VAC
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 25kA at 600VAC
• Series/Frame: PowerPact R
• Trip Unit: Micrologic 5.0
• Certifications: UL, CSA, NOM
• HACR Rated
• Continuous Current Rating: 100%
• Insulation Voltage: 750V IEC 60947-2
• Weight: Approx. 52 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: RJA36120CU33A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Voltage : 600
• Amperage : 1200
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long Time, Short Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Solid State

Product Data

• UPC : 78590183916
• Country of Origin : United States
• Dimensions : 16.24 in (412.50 mm) x 16.54 in (420.12 mm) x 14.49 in (368.05 mm) (Height x Width x Depth)
• Weight : 52.007
• Standards : UL, CSA, NEMA, NMX J-266, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0…600 kcmil aluminium/copper
  4 x AWG 3/0...500 kcmil copper
