Product Info
- Manufacturer:Eaton
Description
RF51070
RF51070 is an Eaton Crouse-Hinds series MTL AirGuard FGT surge protector designed for wideband surge protection in multi-point MMDS/LMDS applications.This surge protector features F(f) bulkhead to F(f) connectors for LMDS/RG 59 cable, providing economic protection with a nominal discharge surge current of 20 kA (8/20 µs) and lightning impulse current of 5 kA (10/350 µs). It operates over a frequency range of DC - 2.5 GHz with 75 Ω impedance.Key Specifications
- Part Number: RF51070
- Manufacturer: Eaton
- Frequency: DC - 2.5 GHz
- Surge Current (8/20): 20 kA
- Lightning Impulse (10/350): 5 kA
- Impedance: 75 Ω
- Connection: F(f) bulkhead to F(f)
Specifications
- Part Number: RF51070
- Manufacturer : Eaton
- Brand : Eaton
- Category : Electrical Components
- Section : Surge protector
- Connection : F(f) bulkhead to F(f) (for LMDS/RG 59 cable)
- Peak Pulse Current : 20 kA
- Breakdown Voltage (VBR@IT)(V) : 5 kA
- Hz : DC - 2.5 GHz
- Impedance (Std) : 75 Ω
Product Data
- Dimensions : 56.6 mm x 18.8 mm x 18.8 mm (Length/Depth x Height x Width)
