Product Info
- Manufacturer:Eaton
Description
RF51058E
RF51058E is an Eaton RF connector surge protector component.
Manufacturer documentation identifies RF51058* models as coaxial protectors with a DC to 2.5 GHz frequency range, 50 ohm impedance, and 40 kA peak pulse current rating.
Key Specifications- Part Number: RF51058E
- Manufacturer: Eaton
- Type: N(f) Bulkhead to SMA(f)
- Frequency Range: DC to 2.5 GHz
- Impedance: 50 ohm
- Peak Pulse Current: 40 kA
- Maximum Discharge Current: 30 kA
- Temperature Range: -40 C to 90 C
- Dust & Waterproof Rating: IP67
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: RF51058E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Electrical Components
- Section : Surge protector
- Type : N(f) Bulkhead to SMA(f)
- Current Rating : 30 kA
- Connection : N/SMA F/F
- Peak Pulse Current : 40 kA
- Breakdown Voltage (VBR@IT)(V) : 470 V
- Operating Temperature Maximum Celsius : -40 C to 90 C
- Hz : DC to 2.5 GHz
- Protection : Surge Protection
- Ingress protection (IP) ratings : IP67
- Minimum Ambient Operating Temperature : -40 deg C
- Maximum Ambient Operating Temperature : 90 deg C
Product Data
- Dimensions : 27.79 mm x 27.79 mm x 27.79 mm (Length/Depth x Height x Width)
