Product Info
- Manufacturer:Eaton
Description
RF51051D
RF51051D is an Eaton Crouse-Hinds series MTL AirGuard GT surge protector. It is a wideband surge protection device for radio telemetry applications with BNC(m) to BNC(f) connectors. The listed specifications include an IP67 ingress protection rating, a DC to 2.5 GHz frequency range, and an operating temperature range from -40 C to 90 C. Key Specifications
- Part Number: RF51051D
- Manufacturer: Eaton
- Type: Wideband surge protection for radio telemetry applications
- Voltage: 350 V
- Connection: BNC(m) to BNC(f)
- Frequency: DC - 2.5 GHz
- Protection: IP67
- Amperage: 40 kA
- Temperature Rating: -40 C to 90 C
Specifications
- Part Number: RF51051D
- Manufacturer : Eaton
- Brand : Eaton
- Category : Electrical Components
- Section : Surge protector
- Type : Wideband surge protection for radio telemetry applications
- Voltage : 350 V
- Amperage : 40 kA
- Connection : BNC(m) to BNC(f)
- Temp Rating : -40 C to 90 C
- Peak Pulse Current : 40 kA
- Hz : DC - 2.5 GHz
- Protection : IP67
- Ingress protection (IP) ratings : IP67
- Minimum Ambient Operating Temperature : -40 deg C
- Maximum Ambient Operating Temperature : 90 deg C
Product Data
- Dimensions : 27.79 mm x 27.79 mm x 27.79 mm (Length/Depth x Height x Width)
- Temp Rating : -40 C to 90 C
