Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
RES-20
RES-20 is a 20 Amp, 600 Volt AC Class H time delay renewable fuse from Eaton designed for reliable circuit protection.This RES-20 fuse features a non-current limiting, Super-Lag time delay characteristic suitable for electrical systems with available fault currents up to 10,000 AIC RMS. It measures approximately 0.81 inches by 5 inches and is designed for easy replacement without multiple links. The fuse is renewable and classified as Class H, making it ideal for applications requiring economical protection with frequent outages.
- Amperage: 20 Amps
- Voltage Rating: 600 Volts AC
- Fuse Type: Renewable, Class H
- Time Delay (Super-Lag) characteristic
- Interrupting Rating: 10,000 AIC RMS
- Physical Size: 0.81" x 5"
- Non-current limiting
- Designed for easy replacement
- Single pole fuse cartridge
- Compatible with Eaton Bussmann fuse blocks
Specifications
- Part Number: RES-20
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Super-Lag
- Type : RES
- Voltage : 600
- Amperage : 20
- AIC rating : 10kA@600V
- Diameter : 0.81
- Class Rating : H
- Barrels : 1
Product Data
- UPC : 051712110204
- GTIN : 00051712110204
- Country of Origin : Mexico
- Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
- Weight : 0.18
