Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
RES-10
RES-10 is a 10 amp, 600 volt Class H renewable fuse from Eaton designed for industrial and commercial electrical protection.
This time delay (slow blow), non-current limiting fuse is part of Eaton's Bussmann series RES fuses, suitable for systems with fault currents less than 10,000 amps RMS symmetrical. It features a 0.81 inch diameter and 5 inch length, with ferrule end connections for easy installation and replacement. The RES-10 fuse is rated for 10kA interrupting capacity and is ideal for protecting non-inductive and motor circuits.
- Key Specifications
- Amperage: 10 A
- Voltage Rating: 600 V AC
- Fuse Size / Group: Class H
- Fuse Type: Time Delay / Slow Blow
- Interrupt Rating: 10,000 A RMS Symmetrical
- Non-Current Limiting
- Physical Size: 0.81 inch diameter x 5 inch length
- Mounting Type: Renewable with ferrule ends
- Part Number: RES-10
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Super-Lag
- Type : RES
- Voltage : 600
- Amperage : 10
- AIC rating : 10kA@600V
- Diameter : 0.81
- Class Rating : H
- Barrels : 1
- UPC : 051712110105
- GTIN : 00051712110105
- Country of Origin : Mexico
- Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
- Weight : 0.18
