REN-25 - Eaton Bussmann 25A 250V Class H Renewable Fuse

REN-25

REN-25 is a 25-amp renewable fuse designed for Class H applications in 250V electrical systems with non-current limiting protection.

The Eaton Bussmann Series REN-25 is a time-delay, super-lag renewable fuse engineered for circuits where the available fault current does not exceed 10,000 amps. This fuse is ideal for applications requiring frequent resets and cost-effective circuit protection. The renewable design allows for replacement of the fuse element without replacing the entire cartridge, reducing maintenance costs. With clip-style termination and rectangular form factor, the REN-25 integrates seamlessly into standard Class H fuse blocks and holders.

• Amperage Rating: 25A
• Voltage Rating: 250V AC
• Fuse Class: Class H
• Fuse Type: Time Delay / Super Lag
• Interrupting Rating: 10,000 Amps RMS Symmetrical
• Renewable: Yes
• Termination Style: Clip
• Current Limiting: Non-current limiting
• Dimensions: 0.56 inch width x 2 inch length (1A-30A range)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: REN-25
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Super-Lag
• Voltage : 250
• Amperage : 25
• AIC rating : 10kA@250V
• Diameter : 0.56
• Class Rating : H
• Barrels : 1

Product Data

• UPC : 051712100250
• Country of Origin : Mexico
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.55
