Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
REN-1
REN-1 is an Eaton Bussmann series renewable Class H time lag fuse designed for industrial and commercial applications.REN-1 fuse features a 1 ampere rating with a voltage rating of 250 volts and an interrupting rating of 10 kAIC. It is a non-current-limiting, non-indicating fuse suitable for protecting non-inductive circuits and motor circuits with recommended sizing at the amp rating or 300% for motor circuits. The fuse has ferrule end connections and is part of Eaton's renewable fuse line, providing reliable circuit protection in a compact form.
- Key Specifications
- Amperage Rating: 1 A
- Voltage Rating: 250 V
- Interrupting Rating: 10 kAIC
- Class: Class H
- Fuse Type: Renewable, Time Lag
- Non-current-limiting
- Non-indicating
- Connection: Ferrule end x ferrule end
- Application: Industrial and commercial structures
Specifications
- Part Number: REN-1
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : Super-Lag
- Type : REN
- Voltage : 250
- Amperage : 1
- AIC rating : 10kA@250V
- Diameter : 0.56
- Class Rating : H
- Barrels : 1
Product Data
- Weight : 5.19
