QPHW2020 - Cutler Hammer 20 Amp 2 Pole 120/240V Quicklag Industrial Thermal-Magnetic Circuit Breaker Bolt-On 22kAIC BAB Frame

QPHW2020

QPHW2020 is a Cutler Hammer Quicklag industrial thermal-magnetic circuit breaker rated for 20 Amps and 120/240 Volts with a 2 pole configuration.This bolt-on mounted circuit breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions. It has an interrupting rating of 22 kAIC at 240V and is UL listed, CSA certified, and HACR rated. The breaker is designed for industrial applications with a BAB frame type and non-interchangeable trip.

• Amperage: 20 A
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 22 kAIC at 240V
• Series/Frame: Quicklag BAB
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Certifications: UL Listed, CSA Certified, HACR Rated
• Dimensions: 3.7" L x 2.2" W x 4.8" H
• Connection Type: Bolt-On

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QPHW2020
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QUICKLAG
• Type : QPHW
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786679387153
• GTIN : 00786679387153
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 2 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : UL Listed,CSA Certified,HACR Rated
