QPHW1020 - Cutler Hammer 20A 1 Pole Thermal Magnetic Circuit Breaker 120/240VAC 22kAIC Bolt-On

QPHW1020

QPHW1020 is a single-pole, thermal magnetic molded case circuit breaker designed for reliable protection in commercial and industrial applications. This Eaton/Cutler-Hammer QBHW series breaker features a 20A current rating, 120/240VAC voltage rating, and a 22kAIC interrupting capacity. It utilizes a bolt-on mounting method and includes long time and instantaneous trip functions for enhanced safety. The breaker is UL Listed and CSA Certified, making it suitable for a wide range of installations. This Quicklag industrial circuit breaker is non-interchangeable and built for durability, with a compact frame size for easy integration into electrical panels. It is HACR rated and suitable for switching duty in 120V fluorescent lighting applications.

• Part Number: QPHW1020
• Manufacturer: Eaton/Cutler-Hammer
• Series: QBHW
• Amperage: 20A
• Voltage: 120/240VAC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 22kAIC
• Frame Type: BAB
• Trip Type: Non-Interchangeable Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QPHW1020
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QUICKLAG
• Type : QPHW
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 22kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786679387061
• GTIN : 00786679387061
• Country of Origin : United States
• Dimensions : 2.9 in x 0.9 in x 2.6 in (Length/Depth x Height x Width)
• Weight : 0.25
• Certification : UL Listed,CSA Certified,HACR Rated
