Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QOXD340
QOXD340 is a 3 pole, 40 amp, bolt-on circuit breaker designed for use in QO panelboards, providing reliable thermal magnetic protection for commercial and industrial applications.This Square D QOXD340 circuit breaker features a 120/240VAC voltage rating, 10kAIC interrupting capacity, and is HACR rated for use with heating, air conditioning, and refrigeration equipment. The breaker is mercury free, RoHS compliant, and includes long time and instantaneous trip functions for enhanced safety and performance.
- Part Number: QOXD340
- Manufacturer: Square D
- Amperage: 40 Amps
- Number of Poles: 3
- Voltage Rating: 120/240VAC, 48VDC
- Mounting Type: Bolt-On
- Interrupting Rating: 10kAIC at 120/240VAC
- Series/Frame: QOB
- Protection Type: Thermal Magnetic
- Trip Functions: Long Time and Instantaneous
- Certifications: UL, CSA, RoHS, REACh, HACR
- Wire Size: AWG 8 to AWG 2 (Copper or Aluminum)
Specifications
- Part Number: QOXD340
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 415
- Amperage : 40
- Phase : 3
- Poles : 3
- AIC rating : 3kA@415V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 785901630265
- GTIN : 00785901630265
- Country of Origin : Mexico
- Dimensions : 3.1 in (80 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 0.86
