QOUQ235 - Square D 35 Amp 2 Pole 120/240V Thermal Magnetic Circuit Breaker

QOUQ235

QOUQ235 is a Square D 2 pole thermal magnetic circuit breaker rated for 35 amps and 120/240 volts AC. It provides reliable overcurrent protection for residential and commercial electrical systems.

This molded case circuit breaker features a 10kA interrupt rating at 120/240VAC and is HACR rated for HVAC applications. It offers instantaneous and time-delayed trip functions to protect circuits from short circuits and overloads. The breaker is UL and CSA certified, designed for easy mounting and OEM use, and supports line side terminal connections.

Key Specifications
• Manufacturer: Square D
• Part Number: QOUQ235
• Amperage: 35 Amps
• Voltage: 120/240 VAC, 48 VDC
• Poles: 2
• Interrupt Rating: 10kA at 120/240 VAC
• Type: Thermal Magnetic Molded Case
• HACR Rated: Yes
• Certifications: UL, CSA
• Mounting: Multiple options, OEM friendly

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOUQ235
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Family : QOU
• Type : QOU
• Voltage : 120/240VAC, 48VDC
• Amperage : 35
• Phase : 1
• Poles : 2
• AIC rating : 10kAIC at 240V
• Connection : Feed-Thru
• Functions : Long-Time and Instantaneous Trip
• Circuit Breaker Mounting Style : Unit
• Mounting : Unit
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 0.77
• Standards : RoHS, HACR
• Certification : UL, CSA, IEC
• Wire Size : AWG 14...AWG 2 aluminium/copper
