QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip

Save $161.37
SKU: QOU280-New
Condition: New
Price:
$97.52 $258.89
Stock:
100+ in stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QOU280 - Square D Bolt-On 80 Amp 2 Pole Circuit Breaker - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QOU280 - Square D Bolt-On 80 Amp 2 Pole Circuit Breaker - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply
QOU280 - Square D 80 Amp 2-Pole Miniature Circuit Breaker, 120/240VAC, 10kA Interrupt, Bolt-On, QOU Series, Thermal Magnetic Trip - Essential Electric Supply

Description

QOU280


QOU280 is a Square D miniature circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This 2-pole, bolt-on circuit breaker features a thermal magnetic trip unit, 80A current rating, and 120/240VAC voltage rating. It is part of the QOU series with an ED frame and offers a 10kA interrupting rating. The breaker is equipped with lugs on both line and load sides for secure connections.

    Key Specifications
  • Part Number: QOU280
  • Manufacturer: Square D
  • Category: Circuit Breaker
  • Amperage: 80A
  • Voltage: 120/240VAC, 60VDC
  • Poles: 2
  • Mounting Type: Bolt-On
  • Interrupt Rating: 10kA @ 120/240VAC
  • Series/Frame: QOU, ED Frame
  • Trip Unit: Thermal Magnetic
  • Certifications: Not specified in available data
  • Termination: Lugs (line and load side)
  • Dimensions: 1.5" W x 2.95" D x 4.45" H (approximate)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: QOU280
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : QOU Series
  • Type : QOU
  • Voltage : 120/240
  • Amperage : 80
  • Phase : 1
  • Poles : 2
  • AIC rating : 10kA@240V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Slotted Box Lug (Non-Reversible Line and Load)
  • Frame Size : 100A/QOU
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 12 AWG Max. Wire Size 2/0 AWG
  • Breaker Type : Standard
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901060260
  • GTIN : 00785901060260
  • Country of Origin : Mexico
  • Dimensions : 4.45 in (113.03 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
  • Weight : 0.94
  • Panel Type : Air Conditioning and Refrigeration Equipment, Heating
  • Standards : CSA, IEC, UL listed
  • Certification : IEC, UL listed
  • Wire Size : AWG 12...AWG 2/0 aluminium/copper
