QOU2501021 - Square D 50A 2 Pole 120/240V AC Miniature Circuit Breaker with Shunt Trip, 10kA Interrupt Rating

QOU2501021

QOU2501021 is a Square D 2 pole miniature circuit breaker rated for 50 amps and 120/240 volts AC with a 10kA interrupt rating and shunt trip feature.This thermal magnetic molded case circuit breaker from the QOU series provides reliable overcurrent protection with a 10,000 amp interrupt capacity at 120/240 VAC. It supports 2 poles and is designed for panel mount applications with slotted box lug terminals compatible with 14 to 2 AWG wire. The breaker includes a shunt trip for remote tripping capability and meets industry certifications for safety and performance.

• Amperage: 50 A
• Voltage: 120/240 VAC, 48 VDC
• Poles: 2
• Interrupt Rating: 10 kA at 120/240 VAC
• Series/Frame: QOU
• Trip Unit: Thermal Magnetic with Shunt Trip
• Mounting Type: Panel Mount
• Terminal Type: Slotted Box Lug
• Wire Size: 14-2 AWG
• Manufacturer: Square D by Schneider Electric
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU2501021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOU Series
• Voltage : 240
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901518006
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.11
• Wire Size : AWG 14...AWG 2 aluminium/copper
