QOU2201042 - Schneider Electric QOU Miniature Circuit Breaker 20A 2P 120/240V 10kA Shunt Trip

QOU2201042

QOU2201042 is a Schneider Electric QOU series miniature circuit breaker designed for reliable protection in residential and commercial applications. This 2-pole breaker features a 20A current rating, 120/240V AC voltage rating, and a 10kA interrupt capacity. It includes a shunt trip for remote operation and is suitable for flush, surface, or DIN rail mounting. The breaker provides visual trip indication and is UL Listed and CSA Certified for safety and compliance. The QOU2201042 is built for HACR and switching duty applications, with lugs on both cable in and cable out connectors. It is tested and listed to UL 489 and CSA C22.2 No. 5 standards, ensuring dependable performance in demanding environments.

• Part Number: QOU2201042
• Manufacturer: Schneider Electric
• Series: QOU
• Amperage: 20A
• Poles: 2
• Voltage Rating: 120/240V AC
• Interrupt Rating: 10kA
• Mounting Type: Flush, Surface, DIN Rail
• Trip Unit: Shunt Trip
• Visual Trip Indication: Yes
• Certifications: UL Listed, CSA Certified
• Application: HACR, Switching Duty

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU2201042
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOU Series
• Type : QOU
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78590158602
• GTIN : 00785901586029
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.06
• Wire Size : AWG 14...AWG 2 aluminium/copper
