Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QOU1151042
QOU1151042 is a 1-pole, 15-amp miniature circuit breaker designed for reliable overcurrent and short-circuit protection in residential and commercial power distribution systems. This Square D QOU series breaker features a shunt trip for remote operation and is built for durability in demanding environments. Engineered for use in QO load centers, the QOU1151042 offers a compact design with slotted box lugs for secure line and load connections. It provides thermal-magnetic protection and is suitable for applications requiring remote tripping capability.
- Part Number: QOU1151042
- Manufacturer: Square D
- Series/Frame: QOU
- Amperage: 15 A
- Poles: 1
- Voltage Rating: 120/240 V AC
- Interrupting Rating: 10 kA at 120/240 V AC
- Mounting Type: Unit mount
- Trip Unit: Shunt trip
- Electrical Connection: Slotted box lugs
- UL Listed
- Application: Residential and commercial
Specifications
- Part Number: QOU1151042
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QOU Series
- Type : QOU
- Voltage : 120
- Amperage : 15
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 00785901585756
- Country of Origin : Mexico
- Dimensions : 4.05 in (102.87 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
- Weight : 0.66 lb
- Certification : UL listed - IEC - CSA
- Wire Size : AWG 14...AWG 2 aluminium/copper
