QOB330VH1021 - Square D 30A 120/240V 3-Pole QOB-VH Miniature Circuit Breaker Bolt-On Mount 22kA Interrupt

QOB330VH1021

QOB330VH1021 is a Square D QOB-VH series miniature circuit breaker designed for reliable protection in electrical systems.This 3-pole circuit breaker is rated for 30 amps and operates at 120/240 volts AC. It features a 22 kiloamp interrupting rating at 120/240 VAC, ensuring high fault current interruption capability. The breaker uses a bolt-on mounting type for secure installation and includes an AC shunt trip for enhanced control. It is HACR rated and UL and CSA certified, meeting rigorous safety and performance standards.

• Amperage: 30 A
• Voltage: 120/240 VAC
• Poles: 3
• Interrupt Rating: 22 kA at 120/240 VAC
• Mounting Type: Bolt-On
• Series/Frame: QOB-VH
• Trip Unit: Thermal Magnetic with AC Shunt Trip
• Certifications: UL, CSA, HACR Rated
• Compact 3/4 inch width design
• Visi-Trip indicator for easy trip detection
• RoHS/REACH compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB330VH1021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901311294
• GTIN : 00785901311294
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 3.0 in (76 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1.21
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 14 to AWG 8, Copper/Aluminum
