QOB3255237 - Square D 25A 3-Pole 120/240V AC Miniature Circuit Breaker Bolt-On Mount 10kA Interrupt Rating

QOB3255237

QOB3255237 is a Square D miniature circuit breaker designed for reliable protection in electrical panelboards.This 3-pole circuit breaker features a 25 ampere rating and supports 120/240 volts AC operation. It has a bolt-on mounting style with ring tongue terminal connections, providing secure installation. The breaker offers a 10 kA interrupt rating at 120/240V AC, ensuring safe interruption of fault currents. It is UL and CSA certified and compatible with NQ/NQOD panelboards.

• Amperage: 25A
• Voltage: 120/240V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kA at 120/240V AC
• Terminal Connection: Ring Tongue
• Series/Frame: QO
• Certifications: UL, CSA
• Compatible Panelboards: NQ/NQOD
• Trip Unit: Standard Thermal-Magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB3255237
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 10kA@120V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Pressure Plate
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 8 AWG (Cu/Al)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 785901116363
• GTIN : 00785901116363
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.83
• Standards : CSA, UL Listed
• Certification : UL Listed
