QOB250VH1021 - Square D 50A 120/240VAC 2-Pole Miniature Circuit Breaker, Bolt-On Mount, 22kA Interrupt, Shunt/Thermal Magnetic Trip

QOB250VH1021

QOB250VH1021 is a Square D 2-pole miniature circuit breaker rated for 50 amps and 120/240 volts AC with a 22 kA interrupt rating and shunt/thermal magnetic trip.QOB250VH1021 features bolt-on mounting and is designed for reliable circuit protection in residential and commercial applications. It includes an AC shunt trip and complies with UL and CSA certifications for safety and performance.

• Amperage: 50 Amps
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 22 kA
• Trip Unit: Shunt/Thermal Magnetic
• Series/Frame: QO
• Certifications: UL, CSA
• Frequency: 50/60 Hz
• Manufacturer: Square D by Schneider Electric

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB250VH1021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901729051
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 8 to AWG 2, Copper/Aluminum
