QOB2451021 - Square D 45 Amp 2 Pole 120/240V Miniature Circuit Breaker Bolt-On Mount

QOB2451021

QOB2451021 is a Square D 2 pole miniature circuit breaker rated for 45 amps and 120/240 volts AC with bolt-on mounting.This thermal magnetic circuit breaker from the QO series features a 10kA interrupt rating at both 120V and 240V, an AC shunt trip, and a fiberglass construction for durability. It provides reliable overcurrent protection with quick make and quick break action and positive handle indication.

• Amperage: 45 Amp
• Voltage Rating: 120/240 VAC
• Number of Poles: 2 Pole
• Interrupt Rating: 10kA at 120V and 240V
• Mounting Type: Bolt-On
• Series/Frame: QO Series
• Trip Unit: Thermal Magnetic with AC Shunt
• Material: Fiberglass
• Toggle Mechanism: Over center, trip free
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB2451021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 10kA@120V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901272151
• GTIN : 00785901272151
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.96
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 8 to AWG 2, Copper/Aluminum
