QOB2201201 - Square D 20 Amp 2 Pole 120/240VAC Circuit Breaker Bolt-On 10kA Interrupting Rating

QOB2201201

QOB2201201 is a Square D 2 pole thermal magnetic circuit breaker rated for 20 Amps and 120/240VAC voltage with bolt-on mounting.This QO series miniature circuit breaker features a 10kA interrupting rating, thermal magnetic trip unit, and includes an auxiliary switch (1B). It is designed for reliable protection in residential and commercial electrical panels.

• Amperage: 20 Amps
• Voltage Rating: 120/240 VAC
• Number of Poles: 2
• Mounting Type: Bolt-On
• Interrupting Rating: 10,000 Amps (10kA)
• Series/Frame: QO
• Trip Unit: Thermal Magnetic
• Auxiliary Switch: 1B Included
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB2201201
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@120V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 3606486144640
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.93
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 14 to AWG 8, Copper/Aluminum
