Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
QOB160VH
QOB160VH is a Square D QO miniature circuit breaker with 60 A rating and thermal-magnetic trip.The QOB160VH provides high interrupt capacity for residential, light commercial, and industrial applications, featuring bolt-on mounting, box lug terminals, and compatibility with 8-2 AWG Al/Cu wire.Key Specifications
- Part Number: QOB160VH
- Manufacturer: Square D
- Amperage: 60 A
- Voltage: 120/240 V
- Poles: 1
- Interrupt Rating: 22 kA@120/240 VAC
- Mounting: Bolt-On
- Frequency: 50/60 Hz
- Trip Type: Thermal Magnetic
- Wire Size: 8-2 AWG Al/Cu
Specifications
- Part Number: QOB160VH
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QOB Series
- Type : QOB
- Voltage : 120/240 V
- Amperage : 60 A
- Phase : 1
- Poles : 1
- AIC rating : 22 kA@120/240 VAC
- Connection : Box Lug
- Terminal Connection : Pressure Plate
- Temp Rating : 104 F
- Wire : 8-2 AWG Al/Cu
- Mounting : Bolt-On
- Hz : 50/60 Hz
- Trip Type : Thermal Magnetic
Product Data
- UPC : 78590173625
- GTIN : 00785901736257
- Country of Origin : Mexico
- Dimensions : 3.1 in (79 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 0.31
- Standards : CSA, UL Listed
- Certification : UL Listed
