QOB115VHAFI - Square D 15A 120/240V 1-Pole Bolt-On Circuit Breaker QO Series

QOB115VHAFI

QOB115VHAFI is a Square D 15 amp, 1-pole bolt-on circuit breaker designed for 120/240 VAC applications.This QO series miniature circuit breaker provides reliable overload and short circuit protection with a 10 kA interrupt rating. It features a bolt-on mounting type, pressure plate terminals, and is HACR and switching duty rated. The breaker supports wire sizes from 14 to 8 AWG copper or aluminum and is UL listed and CSA certified.

• Amperage: 15 A
• Voltage Rating: 120/240 VAC
• Number of Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kA
• Series/Frame: QO
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified
• Wire Size: 14-8 AWG (Cu/Al)
• HACR Rated
• Switching Duty Rated
• Panel Spaces Required: 1

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB115VHAFI
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 22kA@120V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Pressure Plate
• Protection : Thermal Magnetic

Product Data

• UPC : 785901577881
• Dimensions : 4.8 in (121 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.57
• Standards : CSA, UL Listed
• Certification : UL Listed
