Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QO3301042
QO3301042 is a Square D 30 Amp, 3 Pole miniature circuit breaker with shunt trip designed for 120/240VAC applications.This circuit breaker features a plug-in mounting type and supports both AC and DC voltages with a 10kA interrupt rating at 120/240VAC. It is UL and CSA certified, suitable for wire sizes 14 to 2 AWG copper or aluminum, and includes a shunt trip trip unit for remote tripping capability.
- Amperage: 30A
- Voltage Rating: 120/240VAC, 48VDC
- Poles: 3
- Mounting Type: Plug-in
- Interrupt Rating: 10kA at 120/240VAC
- Trip Unit: Shunt Trip
- Wire Size: 14 to 2 AWG Copper/Aluminum
- Certifications: UL Listed, CSA Certified
- Dimensions: 3 in W x 2.95 in D x 4.05 in H
Specifications
- Part Number: QO3301042
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QO Series
- Voltage : 240
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 785901833994
- GTIN : 00785902000000
- Country of Origin : Mexico
- Dimensions : 3.0 in (76 mm) x 3.0 in (76 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 1.21
