QO245GFI - Square D 45 Amp 2 Pole 120/240V GFCI Circuit Breaker, QO Series, Plug-On Mount, 10kA Interrupt, UL Listed

QO245GFI

QO245GFI is a Square D 2-pole ground fault circuit interrupter (GFCI) breaker designed for reliable protection in residential and light commercial applications.

This circuit breaker features a 45 Amp current rating, 120/240V voltage rating, and is compatible with Square D QO series load centers. It offers Class A 6mA ground fault protection, plug-on mounting for easy installation, and a 10kA interrupting capacity. The unit is CSA approved and UL listed for safety and compliance.

Key Specifications
• Part Number: QO245GFI
• Manufacturer: Square D (Schneider Electric)
• Amperage: 45 Amp
• Voltage: 120/240V AC
• Poles: 2
• Mounting Type: Plug-On
• Interrupt Rating: 10kA
• Series/Frame: QO
• Trip Unit: Thermal-Magnetic with Ground Fault
• Ground Fault Trip Level: 6mA (Class A)
• Certifications: UL Listed, CSA Approved
• Connection: Pigtail
• Dimensions: 4.12" H x 1.5" W x 2.91" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO245GFI
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Type : QO
• Voltage : 120/240VAC
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 10kA at 120/240VAC
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic
• Compatible Frames : QO

Product Data

• UPC : 78590150906
• GTIN : 00785901509066
• Country of Origin : Mexico
• Dimensions : 4.1 in (105 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1.031 lb
• Standards : RoHS
• Certification : UL, CSA
