QO240VH - Square D 40 Amp 120/240V 2-Pole Plug-In Circuit Breaker 22kA Interrupt Rating

QO240VH

QO240VH is a Square D 2-pole circuit breaker rated for 40 amps and 120/240 volts AC with a 22kA interrupt rating.This thermal magnetic molded case circuit breaker features a plug-in mounting type compatible with Square D QO load centers. It provides reliable overcurrent protection with a common trip mechanism and is designed for residential and light commercial applications. The breaker meets industry certifications for safety and performance.

Key Specifications
• Amperage: 40 Amps
• Voltage Rating: 120/240 VAC
• Number of Poles: 2
• Mounting Type: Plug-In
• Interrupt Rating: 22,000 Amps (22kA)
• Series/Frame: QO
• Trip Unit: Thermal Magnetic
• Compatible Load Centers: Square D QO
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO240VH
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QO Series
• Type : QO
• Voltage : 120/240
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 22kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 100A/QO
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 2 AWG
• Breaker Type : High Interrupting Capacity
• Protection : Thermal Magnetic

Product Data

• UPC : 785901054955
• GTIN : 00785901054955
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.7
• Panel Type : QO Load Centers and NQ Panelboards
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 8 to AWG 2, Copper/Aluminum
