Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Miniature
Description
QO2305219
QO2305219 is a Square D 30 Amp 2-Pole miniature circuit breaker designed for 120/240 Volt applications with plug-on mounting.This circuit breaker features a thermal magnetic trip unit, a 10kA interrupt rating at 120/240 VAC, and high ampere lugs for reliable circuit protection. It is NEMA AB1 rated and compatible with QO load centers and panelboards. The compact dimensions are approximately 3 in H x 1.5 in W x 2.91 in D, enabling faster installation with a plug-on neutral design.
- Amperage: 30 Amps
- Voltage: 120/240 VAC, 48 VDC
- Poles: 2
- Mounting Type: Plug-On
- Interrupt Rating: 10 kA at 120/240 VAC, 5 kA at 48 VDC
- Series/Frame: QO
- Trip Unit: Thermal Magnetic
- Certifications: UL Listed (UL File E84967), HACR Rated
- Dimensions: 3 in H x 1.5 in W x 2.91 in D
- High Amp Lugs for secure connections
- Frequency: 50/60 Hz
Specifications
- Part Number: QO2305219
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Distribution Equipment
- Item Subcategory : Miniature
- Voltage : 120 to 240 /48 DC 120/240 , 48 DC
Product Data
- UPC : 785901142553
- GTIN : 00785901142553
- Country of Origin : Mexico
- Dimensions : 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 0.59
