QJL22250 - Schneider Electric PowerPact Q-Frame 250A 2 Pole 240VAC 100kA Thermal Magnetic Circuit Breaker

Save $1,037.88
SKU: QJL22250-New
Condition: New
Price:
$1,310.12 $2,348.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QJL22250 - Square D Feed-Thru 240V 250A 2 pole circuit breaker 100kA@240V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QJL22250 - Square D Feed-Thru 240V 250A 2 pole circuit breaker 100kA@240V - Essential Electric Supply

Description

QJL22250


QJL22250 is a 2 pole, 250 amp, 240VAC circuit breaker from the PowerPact Q-Frame series, designed for reliable overcurrent protection and switching in AC systems. This unit features feed-thru connections and thermal magnetic trip technology for precise circuit control and safety. It is UL 489 Listed, CSA, ANCE, and IEC certified for compliance in commercial and industrial applications. The breaker is suitable for use in panelboards and switchgear requiring high interrupting capacity and dependable performance. The QJL22250 is engineered for easy installation and compatibility with a wide range of accessories. Its robust construction ensures long-term reliability in demanding environments. The breaker is ideal for applications where high fault current protection and compliance with safety standards are critical.
  • Part Number: QJL22250
  • Manufacturer: Schneider Electric
  • Series/Frame: PowerPact Q-Frame
  • Amperage: 250A
  • Voltage: 240VAC
  • Poles: 2 Pole
  • Interrupt Rating: 100kA @ 240VAC
  • Mounting Type: Unit Mount
  • Trip Unit: Thermal Magnetic
  • Connections: Feed-Thru
  • Certifications: UL 489 Listed, CSA, ANCE, IEC
  • Application: Overcurrent Protection, Switching
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: QJL22250
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : QJL
  • Voltage : 240
  • Amperage : 250
  • Phase : 1
  • Poles : 2
  • AIC rating : 100kA@240V
  • Connection : Feed-Thru
  • Functions : Long Time and Instantaneous
  • Frame Size : Q Frame
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic

Product Data

  • Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
  • Weight : 3.35
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
  • Certification : UL, CSA, NOM
