QJL22225 - Square D 225A 240V 2 Pole Circuit Breaker Q Frame Feed-Thru

QJL22225

QJL22225 is a Square D 2 pole, 225 amp, 240 volt circuit breaker designed for reliable overcurrent protection in AC systems.QJL22225 features a Q Frame with a feed-thru connection type and a 100kA interrupt rating at 240 VAC. It includes a thermal magnetic trip unit and is UL 489, CSA, ANCE, and IEC certified for safety and performance. This molded case circuit breaker is suitable for unit mount applications and supports lug connections for aluminum or copper conductors.

• Amperage: 225A
• Voltage: 240V AC
• Poles: 2
• Frame Type: Q Frame (QJL)
• Interrupt Rating: 100kA at 240 VAC (Breaking capacity code J)
• Trip Unit: Thermal Magnetic
• Mounting Type: Unit Mount
• Connection Type: Feed-Thru with lugs
• Certifications: UL 489, CSA, ANCE, IEC
• Rated Impulse Withstand Voltage: 8 kV
• Compatible with AWG 4 to 300 KCMIL aluminum/copper conductors

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QJL22225
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : QJL
• Voltage : 240
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : Q Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901774211
• GTIN : 00785901774211
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 3.35
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
